IQBOARD IQShare Button
Original price was: $491.48.$447.80Current price is: $447.80.
Payments starting from $10.00 per week. learn more
7 in stock
Details
- 30 day returns
- Free shipping
- Secure checkout
- 6-month warranty
Stock Availability (LIVE)
- • Queensland Warehouse ✓ In Stock (7)
- • New South Wales Warehouse ✕ Out of Stock (0)
- • Victoria Warehouse ✕ Out of Stock (0)
- • Western Australia Warehouse ✕ Out of Stock (0)
- • South Australia Warehouse ✕ Out of Stock (0)
Call for corporate/edu qty purchases
Same Day Shipping
Order within --:-- for same day dispatch!
Shipping cutoff time: --:--
.IQBOARD IQShare Button
Features
- UFC (Ultra Fast Casting) Technology
- Two buttons with customized button
- Plug & play
- Automatic pairing
- APP Free
- Touchback
- 4K wireless casting
- Wireless BY
Specifications
Interface
- HDMI (19PIN)
- USB-A
- USB-C (With DisplayPort Alternate Mode)
Output Resolution
- 4K@30FPS
Video Standard
- HDMI1.4
- DP1.2
- eDP1.4
USB Standard
- 2.0
Audio
- 16bit 44KHz
USB HID Function
- YES
BYOM Function
- YES
Supported System
- Windows7/8/10, macOS, ChromeOS, Android, Linux
- Any device supports full featured Type-C (DP Alt mode)
Touchback Control
- 10 Points (Linux, Windows, ChromeOS)
- Mouse mode (macOS)
Wireless Transmission Protocol
- IEEE 802.11 a/b/g/n/ac/ax
Wi?Fi Standard
- 2.4 GHz & 5 GHz
Wireless Transmission Frame Rate (depending on environment)
- BYOD mode: Up to 60FPS
- BYOM mode: Up to 30FPS
Input Resolution
- BYOD mode: Up to 4K 30FPS
- BYOM mode: Up to 1080P 30FPS
Audio Rate
- 16bit 44KHz
Distance (between Button and IFP/BOX)
- Max. 30m (depend on network condition)
Authentication Protocol
- WPA2 Personal (WPA2?PSK)
Security (Encryption)
- AES
Button
- Cast button*1
- Custom button*1 (Linux, Windows and macOS are supported)
Power
- 5V, 0.9A, Max 4.5W
Temperature Range
- Operating: 0°C to +40°C (+32°F to +104°F)
- Storage: -10°C to +60°C (+14°F to +140°F)
Humidity Range
- Operating: 10% to 80% relative humidity
- Storage: 5% to 90% relative humidity
Dimension (W*H*D) (mm)
- 63*175*17
Weight (g)
- 80
